Part Number:
1771-IANWeight:
0.5kgDimensions:
2.5 cm x 25.4 cm x 15.2 cmManufacture Year:
2021Place of Origin:
USACertification:
CO,CQDescription:
1771-IAN Digital Input Module
Long Description:
PLC 5 Digital AC/DC Input Module, 32 Inputs (4 Sets of 8), 120 Volts AC/DC Voltage Category, 280 Miliamperes Backplane Current
Technical Specifications for 1771-IAN
Manufacturer Automation
Brand
Part Number/Catalog No. 1771-IAN
Module Type Digital AC/DC Input Module
Number of Inputs 32 Inputs (4 Sets of 8)
Voltage Category 120 Volts AC/DC
AC Operating Voltage 85-138 Volts
DC Operating Voltage N/A
Backplane Current 280 Miliamperes
Max AC Off-State Current 3.0 Miliamperes
Max DC Off-State Current 0.8 Miliamperes
Typical AC Signal Delay (On) 10 (+/- 7) ms
Typical DC Signal Delay (On) N/A
Typical AC Signal Delay (Off) 20 (+/- 15) ms
Typical DC Signal Delay (Off) N/A
Wiring Arm 1771-WN
Product Compatibility. This module must be used with a 1771-A1B thru -A4B
or later I/O chassis. If you are using 1/2-slot addressing, you can use any
combination of I/O modules. When using 1-slot addressing, make sure no other
input module or single slot block transfer module is placed in the same I/O
group. This module is not compatible with 2-slot addressing.
