Siemens 6ES7151-3BA22-0AB0 IM151-3 PN HIGH FEATURE interface product image

Siemens 6ES7151-3BA22-0AB0 IM151-3 PN HIGH FEATURE interface

EMAIL SALES

ET 200S PROFINET

6ES7151-3BA22-0AB0 — IM151-3 PN HIGH FEATURE interface

Use this HIGH FEATURE interface for an ET 200S station engineered on PROFINET IO. Confirm its complete ordering code and software configuration so station diagnostics and communication match the installed hardware.

SiemensET 200S PROFINETIM151-3 PN HIGH FEATURERJ45 copper PROFINET connection

Sales managerTiffany Guan

Mobile / WhatsApp+86 18030235313

Emailsales2@mooreplc.com

6ES7151-3BA22-0AB0 product profile

ManufacturerSiemens

Exact model6ES7151-3BA22-0AB0

Product typeIM151-3 PN HIGH FEATURE interface

Product familyET 200S PROFINET

Primary roleLinks an ET 200S station to its IO controller

Interface contextRJ45 copper PROFINET connection

Brand:
SIEMENS
Item NO.:
6ES7151-3BA22-0AB0

Inquiry now

6ES7151-3BA22-0AB0 configuration inquiry

Get a precise quote for 6ES7151-3BA22-0AB0

Email Sales

Sales managerTiffany Guan

WhatsApp+86 18030235313

Emailsales2@mooreplc.com

IM151-3 PN HIGH FEATURE interface configuration

The HF interface combines a two-port copper Ethernet connection with the configured distributed station. Its network identity, module sequence and supply arrangement must agree with the controller project.

Control-system purposeLinks an ET 200S station to its IO controller.

Connection arrangementRJ45 copper PROFINET connection.

Installation planningCheck the 24 V DC feed and its return connection before restoring power.

Commissioning evidenceConfirm hardware and firmware support for each required feature before commissioning.

Engineering selection points

Ethernet connectors: 2 × RJ45.
Physical layer: 100BASE-TX.
Nominal operating supply: 24 V DC.
Interface current: Approximately 200 mA.

Official product data

6ES7151-3BA22-0AB0 key specifications

Interface designation	IM151-3 PN HIGH FEATURE
Network role	PROFINET IO station interface
Ethernet connectors	2 × RJ45
Physical layer	100BASE-TX
Nominal operating supply	24 V DC
Interface current	Approximately 200 mA
Heat dissipation	Approximately 2 W
Housing width	60 mm

Siemens IM151-3 PN HIGH FEATURE equipment manual; functionality remains dependent on the installed version.

Pre-order check 01

Installation environment

Check the mounting, connection and operating conditions for this exact configuration before installation.

Make the I/O station safe and remove its supply before disconnecting the interface.
Check the 24 V DC feed and its return connection before restoring power.
Retain the station module order and required shielding when fitting the replacement.
Inspect both RJ45 sockets, cable latches and cable routing before the communication test.

Record the installed arrangement and the final controlled checks in the commissioning file.

Pre-order check 02

Compatibility confirmation

Match the complete item to its field interface, mechanical arrangement and configured system.

Interface class: Match the HIGH FEATURE designation as well as the complete ordering code.
Station layout: Compare the installed ET 200S electronic modules and their sequence with the controller project.
Network medium: Use the RJ45 copper connection; do not substitute optical-link assumptions.
Engineering configuration: Preserve device identity, parameter assignments and the controller association.
Version-dependent functions: Confirm hardware and firmware support for each required feature before commissioning.

Keep HIGH FEATURE identity, station configuration and hardware revision aligned in the replacement record.
