Series Six

IC600CB536 — CCM2 communications control circuit board

IC600CB536 provides the covered CCM2 communications-control circuit-board function. Preserve the two interface configurations and the CCM application exchange rather than assuming that a similar communications board offers the same protocol.

General ElectricSeries SixCCM2Two programmable communication interfaces

Sales managerTiffany Guan

Mobile / WhatsApp+86 18030235313

Emailsales2@mooreplc.com

IC600CB536 product profile

ManufacturerGeneral Electric

Exact modelIC600CB536

Product typeCCM2 communications control circuit board

Product familySeries Six

Primary roleTransfers serial data using CCM

Interface contextTwo programmable communication interfaces

Brand:
General Electric
Item NO.:
IC600CB536

Inquiry now

IC600CB536 configuration inquiry

Get a precise quote for IC600CB536

Email Sales

Sales managerTiffany Guan

WhatsApp+86 18030235313

Emailsales2@mooreplc.com

CCM2 communications control circuit board configuration

System roleIC600CB536 provides the covered CCM2 communications-control circuit-board function. Preserve the two interface configurations and the CCM application exchange rather than assuming that a similar communications board offers the same protocol.

Electrical integrationCheck the CPU’s required positive and negative supply rails and the actual port wiring.

Configuration reviewMatch both interface settings and the CCM exchange, including the application’s QAB use.

CommissioningCheck communication indications and verify the expected data transfer at the application level.

Engineering selection points

Communication type: CCM2.
Programmable interfaces: 2.
Configuration controls: 2 switches.
Status indication: 4 LEDs.

Official product data

IC600CB536 key specifications

Communication type	CCM2
Programmable interfaces	2
Configuration controls	2 switches
Status indication	4 LEDs
CCM data facility	1024-byte QAB
CPU supply rails	+5 V, +12 V and -12 V
Operating ambient	0–60 °C

Technical reference: GFK-0238A communications-control instruction sheet, CCM2 circuit-board scope.

Pre-order check 01

Installation environment

Check the mounting, connection and operating conditions for this exact configuration before installation.

Save the interface settings and connected-device identities before board removal.
Isolate the CPU and external connections using the site procedure.
Restore switch settings, cable identification and the required CPU interconnections.
Test the intended CCM exchange and application data before normal operation.

Record the installed arrangement and the final controlled checks in the commissioning file.

Pre-order check 02

Compatibility confirmation

Match the complete item to its field interface, mechanical arrangement and configured system.

Complete item: Retain IC600CB536 and record the supplied board revision.
Installed assembly: Two programmable communication interfaces.
Electrical conditions: Check the CPU’s required positive and negative supply rails and the actual port wiring.
Configuration: Match both interface settings and the CCM exchange, including the application’s QAB use.
Acceptance: Check communication indications and verify the expected data transfer at the application level.

Match the complete supplied identity, board revision and installed circuit requirements before operational release.
