Series Six

IC600BF914 — 6-channel mercury-wetted reed relay output module

IC600BF914 uses six mercury-wetted reed relay outputs. Its required mounting orientation and selected contact arrangement are important installation checks; contact voltage, current and VA limitations must be assessed together for the connected load.

General ElectricSeries Six6 Form C relay outputsSix individually fused Form C outputs

Sales managerTiffany Guan

Mobile / WhatsApp+86 18030235313

Emailsales2@mooreplc.com

IC600BF914 product profile

ManufacturerGeneral Electric

Exact modelIC600BF914

Product type6-channel mercury-wetted reed relay output module

Product familySeries Six

Primary roleSwitches isolated relay contact circuits

Interface contextSix individually fused Form C outputs

Brand:
General Electric
Item NO.:
IC600BF914

Inquiry now

IC600BF914 configuration inquiry

Get a precise quote for IC600BF914

Email Sales

Sales managerTiffany Guan

WhatsApp+86 18030235313

Emailsales2@mooreplc.com

6-channel mercury-wetted reed relay output module configuration

System roleIC600BF914 uses six mercury-wetted reed relay outputs. Its required mounting orientation and selected contact arrangement are important installation checks; contact voltage, current and VA limitations must be assessed together for the connected load.

Electrical integrationAssess the relay’s voltage, current and VA limits together against the actual load and protective arrangement.

Configuration reviewVerify every NO/NC selection and its RC protection arrangement before reconnecting the field circuits.

CommissioningCheck the selected contact behavior and the intended circuit response in the required vertical orientation.

Engineering selection points

Output contacts: 6 Form C relay outputs.
Circuit protection: Individual output fuses.
Status indication: Individual output indicators.
Contact selection: Normally open or normally closed by jumper.

Official product data

IC600BF914 key specifications

Output contacts	6 Form C relay outputs
Circuit protection	Individual output fuses
Status indication	Individual output indicators
Contact selection	Normally open or normally closed by jumper
Default arrangement	Normally open with RC protection
Logic supply	5 VDC; 750 mA maximum
Mounting requirement	Vertical, correct side up

Technical reference: GEK-90494A Relay Output Module instruction sheet.
