Part Number:
1756-IG16Weight:
0.35kgDimensions:
23.5*18.3*5.3cmManufacture Year:
2021Place of Origin:
USACertification:
CO,CQDescription:
1756-IG16 ControlLogix Digital DC Input Module
Description:
1756-IG16 is a Transistor-Transistor Logic (TTL) Input Module. To connect the 1756-IG16
to a ControlLogix 1756 chassis, you need to use a removable terminal block housing or RTB. You can use
either the 1756-TBNH or the 1756-TBSH RTB. When using this module, you should note that TTL inputs are
inverted. That is, the low-true format is -0.2 to 0.8 low voltage = True = On, or the input is guaranteed to in
on-state if it is within this range. If it is between 0.8 to 2.0 Volts, the input state is not guaranteed. And if it is
between 2.0 to 5.5 Volts, the input is guaranteed to be in off-state. The 1756-IG16 module has a voltage category
of 5 Volts DC TTL source (where low means true). Its operating voltage range lies from 4.5 to 5.5 Volts DC and has
a maximum of 50 millivolts P-P ripple.
Technical Specifications for 1756-IF8I
Series ControlLogix
Module Type Digital DC Input Module
Inputs 16-points (9 per common)
Input Voltage 5 Volts DC with TTL Source
Operating Voltage Range 4.5-5.5 Volts DC
Input Delay Time 0.25 milliseconds plus selected filter time
