General Electric Series One

IC610MDL185 — 6-point 115 VAC digital output module

IC610MDL185 is a six-point 115 VAC output module for the GE Series One system. The dedicated original specification lists two three-point groups and a maximum output current of 0.5 A per point.

General ElectricSeries One6-point 115 VAC digital output module

Sales managerTiffany Guan

Mobile / WhatsApp+86 18030235313

Emailsales2@mooreplc.com

IC610MDL185 product profile

Product familySeries One

Exact modelIC610MDL185

Output points6

Operating voltage97–132 VAC

Maximum point current0.5 A

Circuit groupingTwo groups of three

Brand:
General Electric
Item NO.:
IC610MDL185
Part Number:
Weight:
Dimensions:
Manufacture Year:
Place of Origin:
Certification:
Description:

Inquiry now

IC610MDL185 configuration inquiry

Get a precise quote for IC610MDL185

Email Sales

Sales managerTiffany Guan

WhatsApp+86 18030235313

Emailsales2@mooreplc.com

IC610MDL185 functions and installation

IC610MDL185 is a six-point 115 VAC output module for the GE Series One system. The dedicated original specification lists two three-point groups and a maximum output current of 0.5 A per point. Switches appropriate discrete AC loads in the specified voltage and frequency range. Two internal 5 A fuses protect the corresponding three-point groups.

AC load controlSwitches appropriate discrete AC loads in the specified voltage and frequency range.

Grouped protectionTwo internal 5 A fuses protect the corresponding three-point groups.

Load selectionCheck both maximum point current and the smallest recommended load.

Controlled testingVerify point identity and actual load response after the correct output wiring is restored.

Installation and selection boundaries

Output points: 6.
Internal fuses: Two 5 A fuses, one per three-point group.
Select this six-point AC output, not an input module or a different output technology.

Official product data

IC610MDL185 key specifications

Output points	6
Operating voltage	97–132 VAC
AC frequency	47–63 Hz
Maximum point current	0.5 A
Smallest recommended load	25 mA
Internal fuses	Two 5 A fuses, one per three-point group

Source: GE Series One / Series One Plus User’s Manual, GEK-90842C, original manufacturer manual in the authorized archive.

Pre-order check 01

Installation environment

Prepare the actual mounting and connections for IC610MDL185 before installation.

Check the correct rack location, mating connector and mechanical retention before installation.
Isolate the affected supply and field circuits before handling the module or its connections.
Retain the approved wiring and configuration records; keep low-level signals separated from power wiring.
Check the restored installation and perform a controlled functional test before normal operation.

Retain the approved installation drawing and record the controlled acceptance checks.

Pre-order check 02

Compatibility confirmation

Match the complete item, actual connections and required installed function.

Controller arrangement: Use the intended Series One rack and programmed output references.
Field supply: Match 97–132 VAC and 47–63 Hz.
Load current: Keep each point within 0.5 A maximum and consider the 25 mA minimum recommended load.
Groups: Preserve the two three-point group common and fuse arrangement.
Output identity: Select this six-point AC output, not an input module or a different output technology.

Accept the replacement only after its complete identity, installation and required operating function have been checked.

Recommended model families
