ABB PM5675-2ETH-XC control processor

Products
ABB PM5675-2ETH-XC control processor product views
ABB PM5675-2ETH-XC control processor product views
ABB PM5675-2ETH-XC control processor product views

ABB PM5675-2ETH-XC control processor

EMAIL SALES
ABB AC500 V3
PM5675-2ETH-XC — XC control processor

PM5675-2ETH-XC provides two independent Ethernet interfaces in an AC500 V3 processor. Select the terminal base and confirm the hardware revision before restoring the engineered control application.

ABBAC500 V3Control processor
Sales managerTiffany Guan
Mobile / WhatsApp+86 18030235313
PM5675-2ETH-XC product profile
Product familyAC500 V3
Exact modelPM5675-2ETH-XC
Rated supply24 VDC
Ethernet interfacesTwo
Communication expansionUp to 6 base slots; approved CPU order variant or production index ≥ C0 required.
Integrated flash disk8 GB

  • Brand:

    ABB

  • Item NO.:

    PM5675-2ETH-XC
Inquiry now
PM5675-2ETH-XC configuration inquiry

Get a precise quote for PM5675-2ETH-XC

Email Sales
Sales managerTiffany Guan
WhatsApp+86 18030235313
Emailsales2@mooreplc.com

PM5675-2ETH-XC functions and installation

The PM5675-2ETH-XC processor fits a matching two-Ethernet terminal-base assembly. Its display and memory-card provision support local operation and application handling, while the selected base determines the available communication-module arrangement.

Program executionRuns the accepted control application on the matched processor hardware.
Network separationProvides two independent Ethernet connections for the configured network arrangement.
Local operationProvides a display for the processor operating interface.
Base integrationUses a matching terminal assembly for field connections and permitted communication expansion.

Installation and selection boundaries

  • Inspect the actual hardware revision before choosing the firmware and engineering-software version.
  • The communication expansion arrangement is limited to the supported 6-slot base configuration and its revision or production-index conditions.
  • Ethernet protocol availability and application behavior depend on the configured project and applicable software functions.
Official product data

PM5675-2ETH-XC key specifications

Rated supply 24 VDC
Ethernet hardware 2 independent RJ45 Ethernet interfaces
Local operator interface Display
Removable storage Memory-card slot
Terminal assembly Matching two-Ethernet terminal base required
Communication-module capacity Up to 6 terminal-base slots; six-slot use depends on the applicable revision or production index
Serial connection RS-232/RS-485 through the terminal-base arrangement
Integrated mass storage 8 GB flash disk; distinct from application RAM

ABB AC500 processor ordering data and terminal-base combination table.

Pre-order check 01

Installation environment

Prepare the cabinet, wiring and controlled commissioning plan for PM5675-2ETH-XC.

  • Isolate the PM5675-2ETH-XC assembly and verify the cabinet mounting and matched terminal base.
  • Check the 24 VDC supply wiring, polarity, grounding and cable strain relief.
  • Record the hardware revision, project backup, communication settings and actual module sequence.
  • Check processor diagnostics and communications with outputs held safe, then perform the controlled application acceptance test.
Retain the approved installation drawing and record the controlled acceptance checks.
Pre-order check 02

Compatibility confirmation

Match the complete item, actual connections and required installed function.

Terminal assembly
Use a supported two-Ethernet terminal base and inspect the actual connector arrangement.
Expansion capacity
Match the required communication-module count to the supported 6-slot configuration and the applicable revision/production-index restrictions.
Hardware and firmware
Revision 3 requires CPU/boot firmware V3.6.x or newer and cannot be used with firmware below V3.6.0.
Engineering project
When moving an older project to revision 3 hardware, use Automation Builder 2.6.0 or newer and validate the upgraded project.
Installed function
Confirm I/O mapping, interface settings and application acceptance rather than assuming compatibility from the housing.
Confirm the complete processor identity, actual hardware revision, wiring and accepted application before energizing the equipment.
Recommended model families

More ABB models

ABBABB SDCS-UCM-1-COAT 3ADT220090R0008ABB IIMKM02AABB DO525

Separate product references; inclusion does not establish compatibility or interchangeability.

ABBABB CM576-PNIOABB DI525ABB PM573-ETH-XC

Separate product references; inclusion does not establish compatibility or interchangeability.

ABBABB PM583-ETH-XCABB PM591-2ETHABB PM591-ETH-XC

Separate product references; inclusion does not establish compatibility or interchangeability.

ABBABB PM592-ETH-XCABB PM595-4ETH-FABB PM595-4ETH-M-XC

Separate product references; inclusion does not establish compatibility or interchangeability.

Additional published brands

Additional Advantage Models

General ElectricGeneral Electric IC600CB504General Electric IC600CB507General Electric IC600CB513

Separate product references; inclusion does not establish compatibility or interchangeability.

SiemensSiemens 6ES7143-5BF00-0BA0Siemens 6ES7144-5KD00-0BA0Siemens 6ES7144-4PF00-0AB0

Separate product references; inclusion does not establish compatibility or interchangeability.

SiemensSiemens 6ES7144-4JF00-0AB0Siemens 6ES7144-4FF01-0AB0Siemens 6ES7144-1JB31-0XB0

Separate product references; inclusion does not establish compatibility or interchangeability.

SiemensSiemens 6ES7144-1GB31-0XB0Siemens 6GK5308-2FM10-2AA3Siemens 6ES7143-5AH00-0BA0

Separate product references; inclusion does not establish compatibility or interchangeability.

SiemensSiemens 6ES7143-4BF50-0AA0Siemens 6ES7142-6BH00-0AB0Siemens 6GK1143-0TA02

Separate product references; inclusion does not establish compatibility or interchangeability.

Bently NevadaBently Nevada 330854-080-25-05Bently Nevada 330854-080-24-05Bently Nevada 330130-070-01-00

Separate product references; inclusion does not establish compatibility or interchangeability.

Bently NevadaBently Nevada 330130-075-01-00Bently Nevada 330104-00-08-15-02-00Bently Nevada 330102-00-12-10-01-05

Separate product references; inclusion does not establish compatibility or interchangeability.

Bently NevadaBently Nevada 330103-02-04-10-02-CNBently Nevada 330103-02-08-10-02-CNBently Nevada 330905-00-25-05-02-CN

Separate product references; inclusion does not establish compatibility or interchangeability.

Every model above links to an existing Nordwel product page. Send the full part number for configuration and availability confirmation. CHECK WITH SALES

PM5675-2ETH-XC Order Guide

Check the complete requested item against the actual installation before ordering.
1Record the complete codeConfirm PM5675-2ETH-XC, hardware revision and any environmental execution.
2Match the terminal baseCheck the two-Ethernet base and the required communication-slot count.
3Check the firmware planSelect software and firmware suitable for the actual processor revision.
4Identify retained accessoriesRecord the removable card, fitted modules and required supplied items.
5Preserve the control projectRetain the application, address plan and module mapping before the change.
6Validate the machine functionInspect diagnostics, communications and safe process response before handover.

Middle East Demand & Specialist Models

Selected specialist-brand products requested for regional projects and available on Nordwel.

Compare the complete identity, installed hardware and application requirements before selection.
ABBV18345-1010261001

A separate product reference; verify its own installation and configuration.

Specialist model
ABB3HAC061275-001

A separate product reference; verify its own installation and configuration.

Specialist model
ABBPM5132-T-ETH

A separate product reference; verify its own installation and configuration.

Specialist model
ABBPM5112-R-ETH

A separate product reference; verify its own installation and configuration.

Specialist model
ABBPM5072-T-ETH

A separate product reference; verify its own installation and configuration.

Specialist model
ABBPM5072-R-ETH

A separate product reference; verify its own installation and configuration.

Specialist model
Nordwel customer support

Company Services & FAQ

Support for PM5675-2ETH-XC selection, quotation and controlled replacement planning.

Company services

Item and application reviewCompare the complete item with the installed configuration and required supplied scope.
Fast quotation supportConfirm pricing, availability and lead time against current Nordwel business records.
Worldwide shipping coordinationConfirm destination, freight option, packing requirements and shipment tracking workflow.
Order follow-upProvide pre-order clarification and shipment-status support through the assigned sales contact.

PM5675-2ETH-XC FAQ

Does the integrated flash disk in PM5675-2ETH-XC replace user-program memory?No. The specified 8 GB flash disk is a mass-storage feature. Application execution resources have their own definitions and revision-specific limits.
Which environment-related identity must remain on a PM5675-2ETH-XC replacement order?Retain the complete XC ordering identity and the actual hardware revision. Check the approved environmental conditions for the full assembly, not merely a general family name.
What makes a six-slot base acceptable for PM5675-2ETH-XC?The base must be an approved two-Ethernet combination, and the CPU must meet the applicable revision 3 ordering identity or production index C0-or-later condition for six-slot use.
Is a memory card supplied automatically with PM5675-2ETH-XC?The ordering description provides a memory-card slot; it does not by itself define the card supplied with a quotation. Agree the removable medium, application contents and accessory scope explicitly.
What should be checked before transferring network settings to PM5675-2ETH-XC?Compare both Ethernet-interface assignments and any serial settings with the retained station configuration. Confirm that those settings belong to the actual application and installed terminal base.
Can the existing terminal-base wiring be ignored when only PM5675-2ETH-XC is replaced?No. The connections reside on the terminal base, so inspect the mating assembly, connector condition and retained wiring. Reusing a base does not remove the need for an electrical and configuration check.
What is required when a mixed-revision project includes revision 3 PM5675-2ETH-XC?For the migration case described by ABB, all processor modules in the same application must be upgraded to firmware V3.6.x or newer. Check the complete project rather than updating only an isolated device entry.
Does the XC designation on PM5675-2ETH-XC establish hazardous-area certification?It must not be used as a substitute for an applicable hazardous-area approval. Check the exact device markings, installation classification and complete approved assembly before accepting such a use.
How should PM5675-2ETH-XC be tested after restoring application and storage contents?Start from a safe process state, verify the accepted application identity and required files, and then check diagnostics, communications and controlled machine behavior. Restored files alone are not a commissioning pass.
What should accompany a PM5675-2ETH-XC inquiry for a storage-dependent installation?Include the complete CPU code, revision, terminal base, project version and a clear description of the files or storage functions the application needs. Keep hardware supply and application restoration requirements distinct.
