6ES7194-4DD00-0AA0 — CM IO sixteen-M12 fail-safe input connection module

6ES7194-4DD00-0AA0 is a Siemens CM IO sixteen-M12 fail-safe input connection module for ET 200pro installations. It connects field circuits to the matched fail-safe digital input electronics.

SiemensET 200pro16-M12 input connection

Sales managerTiffany Guan

Mobile / WhatsApp+86 18030235313

Emailsales2@mooreplc.com

6ES7194-4DD00-0AA0 product profile

Product familyET 200pro

Exact model6ES7194-4DD00-0AA0

Primary roleFail-safe input field connection

External arrangement16 M12 sockets

Body W × H × D90 × 130 × 39 mm

Identification16 labels plus module label

Brand:
SIEMENS
Item NO.:
6ES7194-4DD00-0AA0
Part Number:
Weight:
Dimensions:
Manufacture Year:
Place of Origin:
Certification:
Description:

Inquiry now

6ES7194-4DD00-0AA0 configuration inquiry

Get a precise quote for 6ES7194-4DD00-0AA0

Email Sales

Sales managerTiffany Guan

WhatsApp+86 18030235313

Emailsales2@mooreplc.com

6ES7194-4DD00-0AA0 functions and installation

6ES7194-4DD00-0AA0 belongs in the connection architecture of the matched ET 200pro installation. Connects field circuits to the matched fail-safe digital input electronics. Keep the terminal hardware, fitted electronics and field-circuit responsibilities distinct when planning a replacement.

Operating purposeConnects field circuits to the matched fail-safe digital input electronics.

Mating arrangementUse the matched fail-safe digital input electronic module.

Field-circuit planningRecord all sixteen socket identities and their assigned field devices.

Return to serviceProve the restored fail-safe input circuits before authorizing process operation.

Installation and selection boundaries

Retain the electronic-module pin map for all sixteen sockets.
Keep sixteen cable labels and the module label associated with the circuit record.
Keep complete application validation separate from the supply of connection hardware.

Official product data

6ES7194-4DD00-0AA0 key specifications

Connection arrangement	CM IO 16 × M12
Circular sockets	16
Socket type	M12
Electronic application	Matched fail-safe digital inputs
Body dimensions W × H × D	90 × 130 × 39 mm
Labelling	16 labels and one module label
Pin mapping	Defined by the selected electronic module

Siemens ET 200pro system documentation. PDF 51–52.

Pre-order check 01

Installation environment

Prepare 6ES7194-4DD00-0AA0 with the equipment safely isolated and its existing connection record available.

Safely isolate the affected input assembly under the site safety-maintenance procedure.
Record all sixteen socket identities and their assigned field devices.
Check connector contact condition, mating fit and screw attachment.
Prove the restored fail-safe input circuits before authorizing process operation.

Retain the approved installation drawing and record the controlled acceptance checks.

Pre-order check 02

Compatibility confirmation

Match the complete item, actual connections and required installed function.

Input electronics: Use the matched fail-safe digital input electronic module.
Field assignment: Retain the electronic-module pin map for all sixteen sockets.
Marking arrangement: Keep sixteen cable labels and the module label associated with the circuit record.
Mechanical space: Check the 90 × 130 × 39 mm body and access for the external cabling.
Safety scope: Keep complete application validation separate from the supply of connection hardware.

Approve the mating arrangement and field-circuit checks before returning the installation to service.
