CI522-MODTCP is a Modbus TCP server interface with eight 24 V DC digital inputs, eight 24 V DC outputs and eight configurable digital channels. Confirm CI522-MODTCP order 1SAP222200R0001, IP settings, Modbus data map, channel direction, terminal unit and device index.
Brand:
ABBItem NO.:
CI522-MODTCPGoods Stock:
1Part Number:
CI522-MODTCPDescription:
CI522-MODTCP Modbus TCP Interface Module for AC500 / S500ABB identifies CI522-MODTCP as a Modbus TCP Interface Module in the AC500 / S500 family. CI522-MODTCP is a Modbus TCP server interface with eight 24 V DC digital inputs, eight 24 V DC outputs and eight configurable digital channels.
| Product family | AC500 / S500 |
|---|---|
| Protocol | Modbus TCP server |
| Digital inputs | 8 × 24 V DC |
| Digital outputs | 8 × 24 V DC, 0.5 A |
| Configurable channels | 8 DC |
| Terminal unit | TU507-ETH or TU508-ETH |
| Order code | 1SAP222200R0001 |
| Weight | 0.20 kg |
Source: ABB CI522 data sheet 3ADR010004 and CI52x system technology.
Verify the Ethernet terminal unit, digital wiring and network identity before replacing the interface module.
Match the interface module to the fieldbus role, integrated digital I/O and terminal unit.
