TU531 is an S500 I/O terminal unit for 120/230 V AC and relay-output modules, using screw terminals. Confirm TU531 order 1SAP217200R0001, the inserted I/O module, voltage class, terminal assignment and screw-terminal requirement.
Brand:
ABBItem NO.:
TU531Goods Stock:
1Part Number:
TU531Description:
TU531 I/O Terminal Unit for AC500 / S500ABB identifies TU531 as an I/O Terminal Unit in the AC500 / S500 family. TU531 is an S500 I/O terminal unit for 120/230 V AC and relay-output modules, using screw terminals.
| Product family | AC500 / S500 |
|---|---|
| Product type | I/O terminal unit |
| Compatible module class | 120/230 V AC and relay I/O |
| Terminal type | Screw |
| Order code | 1SAP217200R0001 |
Source: ABB TU531/TU532 hardware data and AC500 ordering catalog.
Verify the inserted I/O module, voltage class and conductor method before terminal-unit work.
Match the terminal unit to the inserted module, voltage class and required connection method.
