Brand:
OthersPart Number:
RSD-GW3-Ex2.DPEWeight:
0.325kgDimensions:
10x18.8x26.1cmPlace of Origin:
GERMANYCertification:
CO,CQDescription:
Pepperl+Fuchs RSD-GW3-Ex2.DPE Remote IO Systems
Speak to a sales manager for best pricing & lead time:
Sales manager : Tiffany Guan
Mobile / WhatsApp : + 86 18030235313
Email: sales2@mooreplc.com
|
Manufacturer |
Pepperl+Fuchs |
|
Part number |
RSD-GW3-Ex2.DPE |
|
Description |
Pepperl+Fuchs RSD-GW3-Ex2.DPE Remote IO Systems |
|
LEAD TIME |
In Stock |
|
SHIPPING PORT |
Xiamen |
|
PAYMENT |
T/T (Telegraphic Transfer) |
Original new and factory-sealed RSD-GW3-Ex2.DPE in stock!!!
Product Description
RSD-GW3-Ex2.DPE is a PROFIBUS DP-V1 gateway module used in Pepperl+Fuchs remote I/O systems. It works as an interface between the external PROFIBUS DP-V1 network and the internal backplane bus, allowing data exchange between the control system and connected I/O modules. The gateway supports up to 8 I/O modules through the internal backplane bus and provides HART communication between PROFIBUS DP-V1 and connected HART field devices. It supports PROFIBUS communication speeds from 9.6 to 1500 kBit/s, with a cycle time of 1.6 ms on the internal bus. Configuration and parameter settings can be handled through PACTware™ or PROFIBUS DP-V1. The module supports media-redundant PROFIBUS DP operation, DIN rail mounting, and hazardous area applications with EEx ib IIC protection. It operates with a power consumption of 8.5 W and supports ambient temperatures from -20 °C to 70 °C, making it suitable for industrial process automation and remote I/O applications.
Function
The RSD-GW3-Ex2.DPE gateway is the interface between the external PROFIBUS DP-V1 and the internal bus. It converts the protocol of the internal bus to PROFIBUS DP protocol and vice versa. Up to 8 I/O modules can be connected to a gateway via the internal backplane bus. Communication with the I/O modules is performed via the address and data lines of the backplane bus. Configuration and parameter assignment of the system can be performed by PACTwareTM. HART telegrams are received over the PROFIBUS DP-V1 by the gateway and are forwarded on to the HART field devices connected to the I/O modules. HART communication can also be performed with PACTwareTM. The gateway interface with the PROFIBUS DP is designed for media-redundant operation. The internal and external buses are galvanically isolated from the power supply.
Application
Connects conventional binary and analogue sensors as well as actuators to the control system via PROFIBUS DP
HART communication with the field devices connected to the I/O modules
Configuration via PROFIBUS DP
Notes
Parameterisation of the I/O modules connected to the gateway via PROFIBUS DP V1
Parameterisation of the I/O modules connected to the gateway via PROFIBUS DP "User Parameter"
1 power supply channel for 1 gateway
LED "INT" for internal backplane bus; flashes if no communication is taking place with one or more modules or if the
configuration in the master does not agree with the configuration in the modules
LED "EXT" for external PROFIBUS; flashes if no communication is taking place on the external PROFIBUS
LED "RED" for redundant bus line; flashes if no communication is taking place on the redundant transmission line
The gateway must be powered via the intrinsically safe power supplies RSD2-PSD2-Ex4.34 or RSA6-PSD-Ex4.34
|
