Payment:
T/TPart Number:
PQMII-C-AWeight:
1.6kgDimensions:
30x18.5x8mManufacture Year:
The latest yearPlace of Origin:
USACertification:
COODescription:
Module
Parameters
Model: PQMII-C-A
Brand: GE
Condition: Brand New and Origin
Measuring range:
Voltage measurement range: 0 to 600 V ac
Current measurement range: 0 to 5 A ac
Power supply: 90 - 264 V ac/dc or 20 - 60 V dc
Frequency range: 45 to 65 Hz
Measurement accuracy: ±0.2% for voltage and current measurement
Jenny Chan 》》 E-mail: sales3@mooreplc.com 》》 Phone/Whatsapp/Skype: +86 18020714662
Feature
Harmonic measurement: Up to 63rd harmonic can be measured
Communication port: RS485, Ethernet (optional) communication port, RS232 serial port on the front panel, baud rate 1200 to 19,200 bps
Display: LCD display with backlight
Memory: Non-volatile memory for data storage
Related Concerns
Comprehensive measurement functions: It can monitor parameters such as current, voltage, active power, reactive power, energy consumption, energy cost, power factor, frequency, etc., and provides harmonic analysis up to 63 times, including THD and TIF, etc., which can fully understand the power quality of the power system.
Flexible control function: With programmable thresholds and 4 configurable output relays, it can realize over/under current or voltage alarm, unbalance alarm, load shedding based on load demand, and power factor correction control, etc., to meet the control needs in different application scenarios.
