Provides local text display and keypad operation for installed machines. The complete model remains visible for engineering and procurement control.
Brand:
SIEMENSItem NO.:
6AV3505-1FB12Goods Stock:
1Part Number:
6AV3505-1FB12Description:
6AV3505-1FB12 is a OP5/A2 operator panel in the OP5 operator panels family. Provides local text display and keypad operation for installed machines.Provides local text display and keypad operation for installed machines. Selection remains controlled by the complete model and installed-equipment record.
| Exact article number | 6AV3505-1FB12 |
|---|---|
| Product family | OP5 operator panels |
| Product type | OP5/A2 operator panel |
| Primary function | Provides local text display and keypad operation for installed machines |
| Interface | Four-line, 20-character display; TTY/V.24 and RS422/485 communication interfaces |
| Published specification | Legacy operator panel; net weight 0.8 kg |
Source: Siemens Industry Mall product record.
Record the installed conditions before removing or energizing this exact configuration.
Match the complete designation to the host equipment and approved project record.
