Brand:
OthersPart Number:
CP235 143-235-000-012Weight:
0.25kgDimensions:
7.8x5.3x4.8cmPlace of Origin:
SwitzerlandCertification:
CO,CQDescription:
VIBRO-METER CP235 143-235-000-012 Piezoelectric pressure transducer for turbine monitoring
Speak to a sales manager for best pricing & lead time:
Sales manager : Tiffany Guan
Mobile / WhatsApp : + 86 18030235313
Email: sales2@mooreplc.com
|
Manufacturer |
VIBRO-METER |
|
Part number |
CP235 143-235-000-012 |
|
Description |
VIBRO-METER CP235 143-235-000-012 Piezoelectric Pressure Sensor |
|
LEAD TIME |
In Stock |
|
SHIPPING PORT |
Xiamen |
|
PAYMENT |
T/T (Telegraphic Transfer) |
Original new and factory-sealed CP235 143-235-000-012 in stock!!!
Product Description
The Vibro-Meter CP235 143-235-000-012 is a piezoelectric pressure transducer used for dynamic pressure measurement. It is mainly used in gas turbine systems for monitoring pressure pulsations and combustion pressure changes. The sensor uses a piezoelectric sensing element and provides a charge output signal, which can be connected to a charge amplifier or signal conditioner for signal conversion.The CP235 has a sensitivity of 750 pC/bar and a frequency response of 2 to 10000 Hz. It supports pressure measurement in high-temperature environments and is fitted with a mineral insulated cable and high-temperature connector. The sensor is commonly used for gas turbine combustor monitoring, combustion testing, and industrial pressure analysis. It also includes acceleration compensation and can be installed in applications where stable pressure measurement is required under harsh operating conditions.
Parameter Information
Sensitivity: Min. 750 pC/bar (52 pC/psi)
Static pressure range: 0.1 to 20 bar
Overload capacity: Up to 100 bar
Linearity: ≤ ±1%
Frequency response: 2–10000 Hz ±5%
Resonant frequency: >55 kHz
Temperature range: -55 to +520°C
FAQ
CP235 143-235-000-012 overload capacity?
Max. 100 bar.
CP235 143-235-000-012 sensitivity?
Min. 750 pC/bar.
CP235 143-235-000-012 operating temperature?
-55 to +520°C.
