Part Number:
330905-00-23-50-02-00Weight:
0.04kgDimensions:
1.8x1.6x112cmManufacture Year:
LatestPlace of Origin:
USACertification:
COODescription:
330905-00-23-50-02-00 Bently Nevada 3300 NSv Proximity ProbesWelcome to inquiry.
Sales manager:Tiffany Guan
Email:sales2@mooreplc.com
WhatsApp:+86 18030235313
Teams：dddemi33@outlook.com
About the product
Part Number
330905-00-23-50-02-00
Dimensions
1.8x1.6x112cm
Origin
USA
Weight
0.04kg
Brand
Bently Nevada
Warranty
12 month
Electrical
Proximitor Sensor Input
Accepts one non-contacting 3300 RAM or 3300 NSv Proximity Probe and Extension Cable.
Power
Requires -17.5 Vdc to -26 Vdc without barriers at 12 mA maximum consumption, -23 Vdc to -26 Vdc with barriers.
Operation at a more positive voltage than -23.5 Vdc can result in reduced linear range.
Supply Sensitivity
Less than 2 mV change in output voltage per volt change in input voltage.
Output resistance
50 Ω
Product Information
3300 NSv Probe, M10X1 thread, without armor
50 5.0 meters (16.4 feet)
02 Miniature coaxial ClickLoc connector,standard cable
00 Not required
The 3300 XL NSv Proximity Transducer system is intended for use with centrifugal air compressors, refrigeration compressors, process gas compressors, and other machines with tight installation requirements. The 3300 XL NSv Proximity.
Transducer System consists of:
a 3300 NSv probe
a 3300 NSv extension cable
a 3300 XL NSv Proximitor Sensor(1)
|
100% new factory sealed |
|
Warranty: 12 months |
|
All the goods will be tested before shipment |
|
Payment: T/T |
|
Shipped within 1-2 days after payment |
|
Shipment: DHL UPS FedEx, etc (Packed in brand new and original box) |
|
