Bently Nevada 200152-XX-XX-XX MOD 323357-10-03-10 Accelerometer Interface Cable

EMAIL SALES

Official web verified

Modified accelerometer interface cable

The 200152 family is used to connect an acceleration transducer to ProTIM-R wiring and normally has a PT06F8-4S-compatible connector at the transducer end with stripped stranded wires at the ProTIM end. MOD 323357-10-03-10 is retained as a separate configuration identity because its internal changes are not decoded in public manufacturer literature.

200152 cable familyTransducer-to-ProTIMShielded 22 AWGMOD-controlled

Sales managerTiffany Guan

Mobile / WhatsApp+86 18030235313

Emailsales2@mooreplc.com

Officially verified function profile

ManufacturerBently Nevada

Complete identity200152-XX-XX-XX MOD 323357-10-03-10

Product familyAccelerometer interface cable

Transducer endPT06F8-4S or equivalent

Monitoring endStripped stranded wire for ProTIM termination

Conductors4-conductor, 22 AWG shielded cable

Brand:
Bently Nevada
Item NO.:
200152-XX-XX-XX MOD
Part Number:
200152-XX-XX-XX MOD 323357-10-03-10
Description:
Modified accelerometer interface cable

Inquiry now

200152-XX-XX-XX MOD 323357-10-03-10 configuration inquiry

Get a fast quote for 200152-XX-XX-XX MOD 323357-10-03-10

Email Sales

Sales managerTiffany Guan

WhatsApp+86 18030235313

Emailsales2@mooreplc.com

Role in the ProTIM-R signal path

The 200152 cable family connects an acceleration transducer to ProTIM-R wiring. Public Baker Hughes literature describes a PT06F8-4S-compatible transducer-end connector and stripped stranded wires at the monitoring end. MOD 323357-10-03-10 remains a separate configuration identity because its internal changes are not decoded in public manufacturer literature.

Transducer connectionThe standard family uses a PT06F8-4S-compatible connector at the accelerometer end.

Monitoring terminationThe ProTIM-R end is described as stripped stranded wire for field termination.

Cable constructionThe public family description specifies 4-conductor, 22 AWG shielded cable with a PVC outer jacket.

Modification controlKeep MOD 323357-10-03-10 attached to the identity; do not infer its internal changes.

Cable verification checks

Confirm connector mating, pin assignment, cable length and termination against the installed assembly.
Do not replace the modified cable with an unmodified 200152 family item without controlled engineering approval.
Use Baker Hughes ProTIM-R Datasheet 163662 Rev. AK and Accelerometers Datasheet 164986 Rev. Y as the public verification basis.
