Part Number: 330851-01-00-20-10-00-00 (3300 XL 25 mm Proximity Probe)
-
Probe Case Type: ¼‑12 UNF thread (standard, with locknut & pre‑drilled safety wire holes)
-
Unthreaded Length: 0.0 mm (0.0 in)
-
Overall Case Length: 2.0 inches (50.8 mm)
-
Total Probe Length: 1.0 metre (3.3 feet)
-
Armor: None (non‑armored, PFA jacket standard)
-
Agency Approvals: None (00)
-
Tip Material: Polyetheretherketone (PEEK)
-
Case Material: AISI 304 stainless steel
-
Cable: 75 Ω triaxial, PFA‑insulated FluidLoc cable
-
Connector: ClickLoc with removable collar (gold‑plated brass/beryllium copper)
-
Operating Temperature (probe only): Continuous up to +200°C (+392°F); intermittent up to +250°C (+482°F)
-
System Linear Range: 12.7 mm (500 mils) from 0.63 to 13.33 mm (25 to 525 mils)
-
Average Scale Factor: 0.787 V/mm (20 mV/mil) nominal
-
Recommended Target: AISI 4140 steel, 61 mm (2.4 in) diameter or larger (flat)
-
Deviation from Best Fit Straight Line (DSL): < ±0.31 mm (±12 mils) at ambient
-
Pressure Capability: Seals differential pressure (Viton O‑ring + compression seal)
-
Tensile Strength (rated): 330 N (75 lb) probe case to lead; 270 N (60 lb) at connectors
