Part Number:
750-467/006-000Weight:
0.1 kgDimensions:
2.2 cm x 12.4 cm x 12.6 cmManufacture Year:
2022Place of Origin:
USACertification:
CO,CQDescription:
12 BIT RESOLUTION
Overview:
4-channel analog input; 4 … 20 mA; Single-ended
Number of analog inputs 4
Number of Channels 4
Signal type Current
Signal type (current) 4 … 20 mADC
Sensor connection 4 x (2-wire)
Input voltage (max.) 32 V
Signal characteristics Single-ended
Resolution [bit] 12bits
Input resistance (max.) 100Ω
Data width 4 x 16-bit data; 4 x 8-bit control/status (optional)
Conversion time (typ. ≤) 10ms
Measurement error, reference temperature 25°C
Measurement error, deviation max (upper-range value) ≤± 0.1%
Temperature error max. (upper-range value) ≤± 0.01%/K
Supply voltage (system) 5 VDC; via data contacts
Current consumption (5 V system supply) 65mA
Supply voltage (field) 24 VDC (-25 … +30 %); via power jumper contacts (power supply via blade contact; transmission via spring contact)
Isolation 500 V system/field
Manager John quotes to you
sales3@askplc.com
+86 18150117685
we offer original new with 1 year warrenty
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
