Yokogawa identifies ADV869-P00 as an isolated 32-channel input and 32-channel output module for Compatible ST5 in CENTUM VP Field I/O.
Brand:
OthersItem NO.:
ADV869-P00 S1Goods Stock:
1Part Number:
ADV869-P00 S1Weight:
Dimensions:
32.8 x 130 x 125.5 mmManufacture Year:
Place of Origin:
Certification:
Description:
Yokogawa CENTUM VP Field I/O Digital I/O Module for Compatible ST5. Official data: https://web-material3.yokogawa.com/GS33J60F70-01EN.pdfYokogawa identifies ADV869-P00 as an isolated 32-channel input and 32-channel output module for Compatible ST5 in CENTUM VP Field I/O.
| Input channels | 32 |
|---|---|
| Output channels | 32 |
| Isolation | Isolated |
| Common arrangement | Common minus side every 16 channels |
| Suffix function | Pulse-width / time-proportional output |
| Connection cable | KS9 |
Source: Yokogawa General Specification GS 33J60F70-01EN.
Verify the installed module, terminal board, cable, field wiring and environmental conditions before removal or energization.
Match the complete code, style, installed terminal board, cable and field wiring to manufacturer documentation.
ADV869: ST5 digital I/O; ADV859: ST2 digital I/O; ADV159: ST3 digital input.
ADV169: 64-channel input; ADV569: 64-channel output; ADV551: digital output module.
PM861AK01: AC800M processor; PSM0004: power module; CI840A: communication interface.
6GK5208: industrial Ethernet switch; 6ES7153: ET 200M interface; 6ES7214: S7-200 CPU.
1715-A3IO: redundant I/O module; 1768-L43: CompactLogix controller; 1756-ENBT: EtherNet/IP bridge.
323A3347P5: industrial control part; CRS-10-MB: rack accessory; IC693MDL753E: digital output module.
RM7823A1016: burner control; C7232B5820: gas sensor; T7412B1008: control module.
T8313: Trusted interface module; T8123: power device; T7416A1022: control module.
3500/50: speed monitor; 3500/53: overspeed monitor; 330103: proximity probe.
BMXNOR0200H: communication module; BMXDAI1615H: discrete input; BMXNOE0100: Ethernet module.
Related CENTUM VP modules and connection components for configuration review.
Compatible ST2 digital I/O module; verify the complete ordering code.
Compatibility review requiredCompatible ST3 digital input module; verify channel and termination requirements.
Compatibility review required64-channel digital input module; not a direct substitute.
Exact Nordwel page available64-channel digital output module; not a direct substitute.
Compatibility review requiredConnection cable reference for supported terminal-board combinations.
Configuration review requiredTerminal-board family reference for digital I/O connections.
Configuration review requiredMatch the complete code, Style S1, nameplate, terminal board, cable and field-wiring record.
Yokogawa lists ADV869 in CENTUM VP Field I/O as a Digital I/O Module for Compatible ST5.
The official specification lists 32 input channels and 32 output channels.
The module is isolated, with common minus side every 16 channels.
The -P suffix provides pulse-width and time-proportional output functions.
Confirm the ST5-compatible terminal board, KS9 cable, external power and every field-wiring assignment.
Not automatically. Related modules can differ in channel count, compatible terminal board and function.
Keep nameplate images, terminal-board identification, cable details, channel map and controlled functional-test results.
Provide ADV869-P00 S1, quantity, destination, nameplate images, terminal-board code, cable and installed-system context.
Use Yokogawa GS 33J60F70-01EN and the approved project documentation; final suitability depends on the installed configuration.
