Brand:
SIEMENSPart Number:
C98043-A7005-L1/6RY1704-0AA00Weight:
0.18kgDimensions:
26.3x12.5x1.5cmPlace of Origin:
GERMANYCertification:
CO,CQDescription:
SIEMENS C98043-A7005-L1/6RY1704-0AA00 It requires a +5V DC power supply via a flat cable.
Speak to a sales manager for best pricing & lead time:
Sales manager : Tiffany Guan
Mobile / WhatsApp : + 86 18030235313
Email: sales2@mooreplc.com
|
Manufacturer |
SIEMENS |
|
Part number |
C98043-A7005-L1/6RY1704-0AA00 |
|
Description |
SIEMENS C98043-A7005-L1/6RY1704-0AA00 Power Interface Board |
|
LEAD TIME |
In Stock |
|
SHIPPING PORT |
Xiamen |
|
PAYMENT |
T/T (Telegraphic Transfer) |
Original new and factory-sealed C98043-A7005-L1/6RY1704-0AA00 in stock!!!
Product Description
The C98043-A7005-L1 (6RY1704-0AA00) is a specialized Parameterization Unit (PMU) operator control and display board integrated into the chassis door of Siemens SIMOREG DC Master 6RA70 series digital converters. This unit features a 5-digit, 7-segment red LED display, three status monitoring LEDs, and a 4-key membrane keypad, directly mounted to the circuit board for on-site diagnostic, drive state variable readout, and parameter modification. Operating on 5 VDC and 24 VDC logic, the board mounts via four corner screw standoffs to maintain IP20 cabinet compliance and covers fault codes F001 through F060 within an ambient temperature range of 0°C to +60°C.
Parameter Information
Supply Voltage: +5V, ±15V DC
Display: 5-digit LED alphanumeric display, 7-segment digits
Keypad: 7 functional membrane keys
Serial Interface: X300 port, 9-pin D-sub (female)
Protocols: USS protocol via RS232 / RS485 interfaces
Baud Rate: Up to 38.4 kbit/s via X300
Max Distance: 15 meters (RS232) / 1000 meters
Operating Temp: 0°C to +55°C (32°F to 131°F)
Storage Temp: -25°C to +70°C (-13°F to 158°F)
FAQ
Does C98043-A7005-L1 / 6RY1704-0AA00 require a +5V DC power supply to boot up?
Yes. It requires +5V ± 0.25V DC from the main board via the ribbon cable to power its CPU and LED.
Will C98043-A7005-L1 / 6RY1704-0AA00 display fault F040 if the bus communication times out?
Yes. F040 indicates a total communication failure between this PMU board and the main control board.
Can the X300 port on C98043-A7005-L1 / 6RY1704-0AA00 transmit data up to 38.4 kbit/s?
Yes. The maximum supported baud rate for the USS protocol via this port is 38.4 kbit/s.
Application
Metal Processing: Main control pulpits for steel rolling mills, wire drawing plants, and slitting lines.
Paper & Pulp Mills: Multi-drive sectional machinery setups, winders, and heavy calenders.
Plastic & Rubber Manufacturing: High-capacity extruder lines, internal mixers, and blow molding machinery.
Cranes & Material Handling: Control stations for heavy port cranes, mine hoists, and blast furnace skip hoists.
|
