A one-slot, non-isolated 24 VDC backplane power supply with 40 W total capacity and front-panel diagnostic indicators.
Brand:
General ElectricGoods Stock:
1Part Number:
IC695PSD040HDescription:
A one-slot, non-isolated 24 VDC backplane power supply with 40 W total capacity and front-panel diagnostic indicators.Converts the site DC source into supported backplane rails.
Uses one universal-backplane position.
Requires correct source-grounding review.
Keeps the requested detector-margin revision visible.
| Exact catalogue number | IC695PSD040H |
|---|---|
| Nominal input | 24 VDC |
| Operating input range | 18–30 VDC |
| Total output capacity | 40 W across backplane loads |
| Backplane occupancy | One slot |
| Input-to-backplane isolation | None |
| Terminal wire range | AWG 14–22, one conductor per terminal |
| Load sharing / redundancy | Not supported |
| H revision context | Increased 5 V and 3.3 V undervoltage-detector margin |
| Operating temperature | 0 to 60 °C |
| Storage temperature | −40 to +85 °C |
| Relative humidity | 5% to 95%, noncondensing |
Values are limited to published Emerson/GE product, installation or release documentation. The complete suffix is retained for exact-model control.
