A compact signal board for S7-200 SMART with two 24 V DC digital inputs and two 24 V DC transistor outputs rated 0.75 A.
Brand:
SIEMENSItem NO.:
6ES7288-5DT04-0AA0Part Number:
6ES7288-5DT04-0AA0Weight:
18.1 gDimensions:
35 × 52.2 × 16 mmCertification:
CE; IP20Description:
A compact signal board for S7-200 SMART with two 24 V DC digital inputs and two 24 V DC transistor outputs rated 0.75 A.Siemens identifies 6ES7288-5DT04-0AA0 as SB DT04 digital I/O signal board. A compact signal board for S7-200 SMART with two 24 V DC digital inputs and two 24 V DC transistor outputs rated 0.75 A.
Verified SIMATIC S7-200 SMART analog-input and temperature-measurement options.
Verified analog, signal-board and compact I/O choices for S7-200 SMART systems.
Published communication and digital signal-board options with verified contact details.
Expandable S7-200 SMART CPU hosts and compatible compact control choices.
Verified Siemens analog-input, analog-output and temperature-measurement modules.
Verified S7-200 SMART CPUs, communication boards and compact digital I/O.
Published 8 mm and NSv proximity probe configurations.
Verified 5 mm, 11 mm, 25 mm, 50 mm and ceramic-capped probe options.
Verified probe housings, mounting studs and system cable accessories.
Published velocity, thrust, speed and vibration-sensing products.
Verified protection relays, controllers and machinery-monitoring products.
Additional verified automation, monitoring and I/O products published on Nordwel.
Use the exact manufacturer order number and verify the system constraints before procurement.
Confirm exactly two digital inputs and two transistor outputs are required.
Match sensor and load voltage to the documented input and output thresholds.
Keep each transistor output within 0.75 A.
Account for the absence of output short-circuit protection.
Use the documented input and output delays for time-critical signals.
Verify the selected S7-200 SMART CPU accepts SB DT04.
Selected specialist-brand products requested for regional projects and available on Nordwel.
Auxiliary relay option for protection and control applications.
Recent Middle East inquirySIMATIC S7-200 SMART RS485 communication board.
Recent Middle East inquiryRemote I/O gateway for demanding process-system environments.
Specialist brandReplacement inverter driver board for installed industrial systems.
Specialist brandAmplifier transducer for load-cell signal conditioning.
Specialist brandIndustrial power-supply model for legacy equipment support.
Specialist brandAnswers below use Siemens official product documentation for this exact order number.
It is the SIMATIC S7-200 SMART SB DT04 signal board with two digital inputs and two transistor outputs.
The two inputs are designed for 24 V DC signals.
Each of the two transistor outputs is rated 24 V DC and 0.75 A.
No. Siemens states that short-circuit protection is not provided.
The exact data sheet lists 2 µs turn-on and 10 µs turn-off delay values.
Siemens lists 500 m for shielded cable and 300 m for unshielded cable.
The listed module power is 1 W.
SB DT04 measures 35 × 52.2 × 16 mm and weighs about 18.1 g.
