A four-channel thermocouple expansion module for SIMATIC S7-200 SMART, identified by Siemens as EM AT04 with four 16-bit thermocouple inputs.
Brand:
SIEMENSItem NO.:
6ES7288-3AT04-0AA0Part Number:
6ES7288-3AT04-0AA0Weight:
125 gDimensions:
45 × 100 × 81 mmCertification:
Official Siemens data verifiedDescription:
A four-channel thermocouple expansion module for SIMATIC S7-200 SMART, identified by Siemens as EM AT04 with four 16-bit thermocouple inputs.Siemens identifies 6ES7288-3AT04-0AA0 as EM AT04 thermocouple input module. A four-channel thermocouple expansion module for SIMATIC S7-200 SMART, identified by Siemens as EM AT04 with four 16-bit thermocouple inputs.
Verified SIMATIC S7-200 SMART analog-input and temperature-measurement options.
Verified analog, signal-board and compact I/O choices for S7-200 SMART systems.
Published communication and digital signal-board options with verified contact details.
Expandable S7-200 SMART CPU hosts and compatible compact control choices.
Verified Siemens analog-input, analog-output and temperature-measurement modules.
Verified S7-200 SMART CPUs, communication boards and compact digital I/O.
Published 8 mm and NSv proximity probe configurations.
Verified 5 mm, 11 mm, 25 mm, 50 mm and ceramic-capped probe options.
Verified probe housings, mounting studs and system cable accessories.
Published velocity, thrust, speed and vibration-sensing products.
Verified protection relays, controllers and machinery-monitoring products.
Additional verified automation, monitoring and I/O products published on Nordwel.
Use the exact manufacturer order number and verify the system constraints before procurement.
Match the quotation to 6ES7288-3AT04-0AA0, including every suffix character.
Use the module only for the thermocouple types supported by the Siemens system manual.
Reserve up to 40 mA external demand and the documented backplane current.
Choose 10, 50, 60 or 400 Hz filtering for the required noise rejection and response.
Limit thermocouple wiring to 100 m and conductor resistance to 100 Ω.
Account for the documented 500 V AC field-to-logic and field-to-supply isolation.
Selected specialist-brand products requested for regional projects and available on Nordwel.
Auxiliary relay option for protection and control applications.
Recent Middle East inquirySIMATIC S7-200 SMART RS485 communication board.
Recent Middle East inquiryRemote I/O gateway for demanding process-system environments.
Specialist brandReplacement inverter driver board for installed industrial systems.
Specialist brandAmplifier transducer for load-cell signal conditioning.
Specialist brandIndustrial power-supply model for legacy equipment support.
Specialist brandAnswers below use Siemens official product documentation for this exact order number.
It is the SIMATIC S7-200 SMART EM AT04 expansion module with four 16-bit thermocouple analog inputs.
No. The exact Siemens entry specifies thermocouple inputs; voltage, current, RTD and resistance measurement are not listed.
It requires 24 V DC and Siemens specifies an operating range of 20.4 to 28.8 V.
The documented typical demand is 30 mA and maximum demand is 40 mA.
The system manual lists 10, 50, 60 and 400 Hz filter selections.
The documented display resolution is 0.1 °C or 0.1 °F.
Siemens lists a maximum of 100 m, with conductor resistance limited to 100 Ω.
The module measures 45 × 100 × 81 mm and the listed weight is 125 g.
