A four-axis control module documented for servo-drive and stepper-motor tasks, with a 24 V DC supply requirement and onboard digital outputs.
Brand:
SIEMENSItem NO.:
6ES7357-4AH01-0AE0Goods Stock:
1Part Number:
6ES7357-4AH01-0AE0Description:
A four-axis control module documented for servo-drive and stepper-motor tasks, with a 24 V DC supply requirement and onboard digital outputs.A four-axis control module documented for servo-drive and stepper-motor tasks, with a 24 V DC supply requirement and onboard digital outputs.
| Article number | 6ES7357-4AH01-0AE0 |
|---|---|
| Module | FM 357-2 |
| Controlled axes | 4 |
| Supported drive tasks | Servo and stepper motor |
| Supply | 24 V DC |
| Rated input current | 1.9 A |
| Digital outputs | 8 |
| Output voltage | 24 V DC |
| Output current | 0.25 A / 0.5 A |
Source: Siemens FM 357-2 installation and parameter-assignment manual.
Prepare 6ES7357-4AH01-0AE0 from documented physical, electrical and project conditions before work begins.
Approve 6ES7357-4AH01-0AE0 only when every listed selection boundary agrees with the installed system.
Use this group when confirm the axis plan, motor type and feedback devices.
Compare each candidate against four controlled axes and matching transducer interfaces.
Keep drive, encoder and front-connector paths defined in the fm 357-2 manual as its own decision.
Release only with axis map, encoder records, 24 v load calculation and cable schedule.
The four-axis motion coordination requirement stays traceable to the approved project.
Do not extend data beyond this boundary: Apply the four-axis and electrical data only to 6ES7357-4AH01-0AE0 and confirm every connected drive and transducer from the installed documentation.
Catalog checkpoint: The manufacturer manual identifies the exact article as FM 357-2 for four-axis control of servo drives and stepper motors.
Configuration checkpoint: The nameplate data list 24 V DC at 1.9 A and eight 24 V DC digital outputs.
Use installed evidence to close the remaining site-specific checks for 6ES7357-4AH01-0AE0.
Confirm quantity and destination only after the technical record is complete.
Inspect received labels and connections before the item reaches the cabinet.
Selected specialist-brand products requested for regional projects and available on Nordwel.
Output-module reference for control-system projects.
Tiffany-verified targetEthernet-module reference for network compatibility review.
Tiffany-verified targetProximity-sensor reference for machinery applications.
Tiffany-verified targetAccelerometer reference for vibration-monitoring projects.
Tiffany-verified targetProcessor-module reference for installed control systems.
Tiffany-verified targetAnalog-input board reference for replacement review.
Tiffany-verified targetCreate an axis matrix that links connector, drive, motor, encoder and machine name for each channel; verify both ends before disconnection.
Include it in the 24 V load calculation and confirm voltage remains within the approved supply design during simultaneous axis activity.
No. Use the project-specific interface and parameter assignment for the connected motor technology; the manual supports both tasks but does not make their wiring equivalent.
Test each assigned output against its documented field action or simulated load while observing the site interlock procedure.
Provide transducer type, connector views, cable labels, axis assignment and any external interface hardware listed in the electrical drawing.
Record homing method, reference coordinates, offsets and safe travel limits before shutdown, then execute the approved re-reference sequence.
Encoder and drive signals can be sensitive to routing and termination changes; photographs preserve the as-found installation for controlled restoration.
No. Axis capacity alone is insufficient; the exact article, interfaces, project configuration and installed connectors must all agree.
Power the module with drives inhibited, confirm diagnostics and axis identification, then enable and test each motion path under the machine safety procedure.
Close it only after reference, direction, position accuracy, limit behavior, digital outputs and coordinated motion have passed the signed acceptance plan.
