PFRL101B-1.0KN 3BSE023315R0005 Pressductor Radial Force Transducer

ABB PFRL101B-1.0KN 3BSE023315R0005 Pressductor Radial Force Transducer

EMAIL SALES

ABB official data reviewed

PFRL101B-1.0KN 3BSE023315R0005 — Pressductor Radial Force Transducer

An ABB PFRL 101B radial-force transducer configuration with a 1.0 kN rated load for web-tension measurement.

PFRL 101 radial-force transducersWeb-tension and radial-force measurementExact-order review

Sales managerTiffany Guan

Mobile / WhatsApp+86 18030235313

Emailsales2@mooreplc.com

Officially reviewed product profile

Product familyPFRL 101 radial-force transducers

Exact modelPFRL101B-1.0KN 3BSE023315R0005

Verified functionWeb-tension and radial-force measurement

Manufacturer sourceABB Pressductor radial-force transducer catalog 3BSE030912R0303

Transducer modelPFRL 101B

Selection basisConfirm the order code, 1.0 kN rating, load direction, mounting dimensions, cable arrangement and measurement electronics.

Brand:
ABB
Item NO.:
PFRL101B-1.0KN 3BSE0
Goods Stock:
1
Part Number:
PFRL101B-1.0KN 3BSE023315R0005
Description:
An ABB PFRL 101B radial-force transducer configuration with a 1.0 kN rated load for web-tension measurement.

Inquiry now

PFRL101B-1.0KN 3BSE023315R0005 configuration inquiry

Get a precise quote for PFRL101B-1.0KN 3BSE023315R0005

Email Sales

Sales managerTiffany Guan

WhatsApp+86 18030235313

Emailsales2@mooreplc.com

PFRL101B-1.0KN 3BSE023315R0005 official identification

An ABB PFRL 101B radial-force transducer configuration with a 1.0 kN rated load for web-tension measurement.

System responsibilityWeb-tension and radial-force measurement

Connection boundaryMechanical pillow-block load path with the approved Pressductor measurement chain

Procurement decisionConfirm the order code, 1.0 kN rating, load direction, mounting dimensions, cable arrangement and measurement electronics.

Acceptance recordNameplate, mounting drawing, zero-load reading, direction check, calibration record and controlled tension test

Engineering and installation checks

Retain PFRL101B-1.0KN 3BSE023315R0005 as the controlling inquiry identity.
Keep the applied force aligned with the documented measuring direction.
Use only facts traceable to ABB Pressductor radial-force transducer catalog 3BSE030912R0303.

Official product data

PFRL101B-1.0KN 3BSE023315R0005 key specifications

Exact order code	3BSE023315R0005
Transducer model	PFRL 101B
Rated load	1.0 kN (225 lb)
Extended load	1.5 kN (337 lb)
Overload in measuring direction	5.0 kN (1125 lb)
Axial overload	5.0 kN (1125 lb)
Spring constant	100 kN/mm
Operating temperature	−10 to +80 °C

Source: ABB Pressductor radial-force transducer catalog 3BSE030912R0303.

Pre-order check 01

Installation environment

Prepare PFRL101B-1.0KN 3BSE023315R0005 by recording the installed connections, configuration and complete nameplate.

Keep the applied force aligned with the documented measuring direction.
Confirm the pillow-block geometry and mounting surfaces are clean and flat.
Protect the transducer cable from strain and roll-related mechanical damage.
Zero and calibrate the complete measurement chain after mechanical installation.

Close the work with nameplate, mounting drawing, zero-load reading, direction check, calibration record and controlled tension test.

Pre-order check 02

Compatibility confirmation

Approve PFRL101B-1.0KN 3BSE023315R0005 only when its documented function and every listed boundary agree with the installed design.

Order identity: PFRL101B-1.0KN / 3BSE023315R0005
Rated force: 1.0 kN
Mechanical fit: PFRL 101B mounting drawing
Load direction: Approved radial-force orientation
Electronics: Compatible Pressductor signal-processing chain

Final selection: ABB official material verifies the PFRL 101B 1.0 kN mechanical and environmental data. The full 3BSE order code remains the procurement identity.
