A 40-point compact serial CPU that combines 24 digital inputs and 16 relay outputs in a fixed, non-expandable controller.
Brand:
SIEMENSItem NO.:
6ES7288-1CR40-0AA1Part Number:
6ES7288-1CR40-0AA1Weight:
440 gDimensions:
125 × 100 × 81 mmCertification:
CEDescription:
A 40-point compact serial CPU that combines 24 digital inputs and 16 relay outputs in a fixed, non-expandable controller.Siemens identifies 6ES7288-1CR40-0AA1 as the SIMATIC S7-200 SMART CPU CR40s (AC/DC/Relay). A 40-point compact serial CPU that combines 24 digital inputs and 16 relay outputs in a fixed, non-expandable controller.
SR CPUs combine AC supply, 24 V DC inputs and relay outputs across several onboard I/O sizes.
ST CPUs provide DC/DC/DC architecture for high-speed transistor-output applications.
Compact CR and CRs controllers cover fixed-I/O relay projects in multiple point counts.
Published S7-200 SMART digital and analog expansion options for compatible expandable CPUs.
Selected ABB control, I/O and measurement products already published on Nordwel.
Selected Honeywell controller, IOTA and Safety Manager products published on Nordwel.
Selected GE turbine-control, communication and I/O products published on Nordwel.
Square D belongs to Schneider Electric; these linked Schneider products are already published on Nordwel.
Selected Bently Nevada 330904 NSv proximity probes with verified Nordwel contact details.
Selected Vibro-Meter proximity and vibration sensor products published on Nordwel.
Selected Bently Nevada 330904 and 330905 NSv proximity probes with verified Nordwel contact details.
Selected Bently Nevada 330905, 330910 and 3500 system products with verified Nordwel contact details.
Use the exact Siemens order number and verify the system constraints before procurement.
Confirm the machine needs no more than 24 digital inputs and 16 relay outputs.
Verify every switched load remains within the 2 A relay rating and the documented DC or AC voltage range.
Select RS485 cabling, protocol and baud rate before panel wiring.
Choose this CPU only when no expansion module, signal board or memory card is required.
Selected specialist-brand products requested for regional projects and available on Nordwel.
Auxiliary relay option for protection and control applications.
Recent Middle East inquirySIMATIC S7-200 SMART RS485 communication board.
Recent Middle East inquiryRemote I/O gateway for demanding process-system environments.
Specialist brandReplacement inverter driver board for installed industrial systems.
Specialist brandAmplifier transducer for load-cell signal conditioning.
Specialist brandIndustrial power-supply model for legacy equipment support.
Specialist brandAnswers below use Siemens official product documentation for this exact order number.
It is the SIMATIC S7-200 SMART CPU CR40s, an AC-powered compact serial CPU with 24 digital inputs and 16 relay digital outputs.
There are 40 onboard points: 24 inputs and 16 relay outputs.
No. Siemens classifies this compact CPU as fixed I/O with no expansion-module or signal-board support.
The CPU accepts 85 to 264 V AC at 47 to 63 Hz.
Each dry-contact relay output is rated up to 2 A, with a documented switching range of 5–30 V DC or 5–250 V AC.
It provides 12 KB of program memory, 8 KB of data memory and 2 KB of retentive memory.
Yes. Siemens specifies four 100 kHz single-phase counters or two 50 kHz quadrature counters.
Siemens specifies STEP 7 Micro/WIN SMART for engineering the S7-200 SMART CPU.
