An eight-point sourcing MOSFET output module for fast 24 V DC switching in expandable SIMATIC S7-200 SMART stations.
Brand:
SIEMENSItem NO.:
6ES7288-2DT08-0AA0Part Number:
6ES7288-2DT08-0AA0Weight:
147 gDimensions:
45 × 100 × 81 mmCertification:
CE; IP20Description:
An eight-point sourcing MOSFET output module for fast 24 V DC switching in expandable SIMATIC S7-200 SMART stations.Siemens identifies 6ES7288-2DT08-0AA0 as the SIMATIC S7-200 SMART EM DT08 / DQ 8 × 24 V DC Transistor. An eight-point sourcing MOSFET output module for fast 24 V DC switching in expandable SIMATIC S7-200 SMART stations.
Published digital and analog input modules for adding field signals.
Sourcing MOSFET options for fast 24 V DC output expansion.
Dry-contact relay options for documented AC and DC field loads.
Published standard S7-200 SMART CPUs that support expansion-module architectures.
Selected ABB control, I/O and measurement products already published on Nordwel.
Selected Honeywell controller, IOTA and Safety Manager products published on Nordwel.
Selected GE turbine-control, communication and I/O products published on Nordwel.
Square D belongs to Schneider Electric; these linked Schneider products are already published on Nordwel.
Selected Bently Nevada 330904 NSv proximity probes with verified Nordwel contact details.
Selected Vibro-Meter proximity and vibration sensor products published on Nordwel.
Selected Bently Nevada 330904 and 330905 NSv proximity probes with verified Nordwel contact details.
Selected Bently Nevada 330905, 330910 and 3500 system products with verified Nordwel contact details.
Use the exact Siemens order number and verify the system constraints before procurement.
Use 24 V DC loads that are compatible with a P-switching MOSFET output stage.
Keep the sum of assigned point currents within 3 A for each group.
Fuse branch circuits and suppress inductive loads because short-circuit protection is not integrated.
Reserve eight consecutive digital-output bits on an expandable S7-200 SMART CPU.
Selected specialist-brand products requested for regional projects and available on Nordwel.
Auxiliary relay option for protection and control applications.
Recent Middle East inquirySIMATIC S7-200 SMART RS485 communication board.
Recent Middle East inquiryRemote I/O gateway for demanding process-system environments.
Specialist brandReplacement inverter driver board for installed industrial systems.
Specialist brandAmplifier transducer for load-cell signal conditioning.
Specialist brandIndustrial power-supply model for legacy equipment support.
Specialist brandAnswers below use Siemens official product documentation for this exact order number.
It is the SIMATIC S7-200 SMART EM DT08 expansion module with eight 24 V DC sourcing transistor outputs.
No. All eight channels are digital outputs.
Siemens rates each point at 0.75 A, with a maximum of 3 A for each common group.
The documented operating range for the output supply is 20.4 to 28.8 V DC.
For resistive loads, the maximum delay is 50 µs from 0 to 1 and 200 µs from 1 to 0.
No. Siemens specifies no short-circuit protection; provide suitable external protection.
The module measures 45 × 100 × 81 mm, weighs 147 g and consumes 1.5 W.
No. Those compact CR CPUs do not accept EM expansion; use a compatible expandable S7-200 SMART CPU.
