A 32-channel mixed digital module joining sixteen 24 V DC inputs with sixteen fast sourcing MOSFET outputs in a 70 mm rail footprint.
Brand:
SIEMENSItem NO.:
6ES7288-2DT32-0AA0Part Number:
6ES7288-2DT32-0AA0Weight:
257.3 gDimensions:
70 × 100 × 81 mmCertification:
CE; IP20Description:
A 32-channel mixed digital module joining sixteen 24 V DC inputs with sixteen fast sourcing MOSFET outputs in a 70 mm rail footprint.Siemens identifies 6ES7288-2DT32-0AA0 as the SIMATIC S7-200 SMART EM DT32 / 16 DI + 16 Transistor DQ. A 32-channel mixed digital module joining sixteen 24 V DC inputs with sixteen fast sourcing MOSFET outputs in a 70 mm rail footprint.
Published digital and analog input modules for adding field signals.
Sourcing MOSFET options for fast 24 V DC output expansion.
Dry-contact relay options for documented AC and DC field loads.
Published standard S7-200 SMART CPUs that support expansion-module architectures.
Selected ABB control, I/O and measurement products already published on Nordwel.
Selected Honeywell controller, IOTA and Safety Manager products published on Nordwel.
Selected GE turbine-control, communication and I/O products published on Nordwel.
Square D belongs to Schneider Electric; these linked Schneider products are already published on Nordwel.
Selected Bently Nevada 330904 NSv proximity probes with verified Nordwel contact details.
Selected Vibro-Meter proximity and vibration sensor products published on Nordwel.
Selected Bently Nevada 330904 and 330905 NSv proximity probes with verified Nordwel contact details.
Selected Bently Nevada 330905, 330910 and 3500 system products with verified Nordwel contact details.
Use the exact Siemens order number and verify the system constraints before procurement.
Use sourcing-compatible 24 V DC actuators; this model does not provide dry relay contacts.
Keep each group of four outputs at or below the 3 A common limit.
Choose one supported delay for each group of four inputs.
Include 185 mA of SM-bus demand and 4 mA for every used input.
Selected specialist-brand products requested for regional projects and available on Nordwel.
Auxiliary relay option for protection and control applications.
Recent Middle East inquirySIMATIC S7-200 SMART RS485 communication board.
Recent Middle East inquiryRemote I/O gateway for demanding process-system environments.
Specialist brandReplacement inverter driver board for installed industrial systems.
Specialist brandAmplifier transducer for load-cell signal conditioning.
Specialist brandIndustrial power-supply model for legacy equipment support.
Specialist brandAnswers below use Siemens official product documentation for this exact order number.
DT32 uses sixteen sourcing transistor outputs; DR32 uses sixteen dry-contact relay outputs. Both have sixteen digital inputs.
It has 32 channels: sixteen digital inputs and sixteen digital outputs.
Each sourcing MOSFET output is rated 0.75 A, with 3 A maximum per common group.
No. Its outputs are 24 V DC transistors. Use suitable interface devices or choose a relay-output design.
Yes. Filter times from 0.2 through 12.8 ms are selected in groups of four inputs.
No. Provide external fusing and suppression as required by the field loads.
Siemens lists 185 mA from the SM bus.
It measures 70 × 100 × 81 mm and weighs 257.3 g.
