A sixteen-channel dry-contact output module for mixed-voltage switching when no additional digital inputs are required.
Brand:
SIEMENSItem NO.:
6ES7288-2QR16-0AA0Part Number:
6ES7288-2QR16-0AA0Weight:
221 gDimensions:
45 × 100 × 81 mmCertification:
CE; IP20Description:
A sixteen-channel dry-contact output module for mixed-voltage switching when no additional digital inputs are required.Siemens identifies 6ES7288-2QR16-0AA0 as the SIMATIC S7-200 SMART EM QR16 / DQ 16 × Relay. A sixteen-channel dry-contact output module for mixed-voltage switching when no additional digital inputs are required.
Published digital and analog input modules for adding field signals.
Sourcing MOSFET options for fast 24 V DC output expansion.
Dry-contact relay options for documented AC and DC field loads.
Published standard S7-200 SMART CPUs that support expansion-module architectures.
Selected ABB control, I/O and measurement products already published on Nordwel.
Selected Honeywell controller, IOTA and Safety Manager products published on Nordwel.
Selected GE turbine-control, communication and I/O products published on Nordwel.
Square D belongs to Schneider Electric; these linked Schneider products are already published on Nordwel.
Selected Bently Nevada 330904 NSv proximity probes with verified Nordwel contact details.
Selected Vibro-Meter proximity and vibration sensor products published on Nordwel.
Selected Bently Nevada 330904 and 330905 NSv proximity probes with verified Nordwel contact details.
Selected Bently Nevada 330905, 330910 and 3500 system products with verified Nordwel contact details.
Use the exact Siemens order number and verify the system constraints before procurement.
Select QR16 when dry contacts or AC switching are required and high-speed pulses are not.
Assign loads so no group exceeds the documented 8 A maximum.
Compare switching rate and load type with the 100,000-cycle rated-load figure.
Reserve 150 mA at 24 V DC when all sixteen relays may be energized.
Selected specialist-brand products requested for regional projects and available on Nordwel.
Auxiliary relay option for protection and control applications.
Recent Middle East inquirySIMATIC S7-200 SMART RS485 communication board.
Recent Middle East inquiryRemote I/O gateway for demanding process-system environments.
Specialist brandReplacement inverter driver board for installed industrial systems.
Specialist brandAmplifier transducer for load-cell signal conditioning.
Specialist brandIndustrial power-supply model for legacy equipment support.
Specialist brandAnswers below use Siemens official product documentation for this exact order number.
Siemens describes it as a sixteen-output relay module. It is output-only, unlike the mixed 8 DI/8 DQ EM DR16.
There are sixteen dry-contact digital outputs.
The official range is 5–30 V DC or 5–250 V AC.
Each point is rated 2 A and each common group is limited to 8 A.
Siemens lists 150 mA at 24 V DC when all relays are on, plus 110 mA from the SM bus.
No. Each field circuit needs correctly selected external protection.
The official system manual lists 100,000 open/close cycles at rated load.
The module measures 45 × 100 × 81 mm, weighs 221 g and consumes 4.5 W.
