A one-channel S7-200 SMART analog input signal board supporting four official voltage or current ranges with up to 12-bit resolution including sign.
Brand:
SIEMENSItem NO.:
6ES7288-5AE01-0AA0Part Number:
6ES7288-5AE01-0AA0Weight:
20 gDimensions:
35 × 52.2 × 16 mmCertification:
China RoHS documentationDescription:
A one-channel S7-200 SMART analog input signal board supporting four official voltage or current ranges with up to 12-bit resolution including sign.Siemens identifies 6ES7288-5AE01-0AA0 as SB AI01 analog input signal board. A one-channel S7-200 SMART analog input signal board supporting four official voltage or current ranges with up to 12-bit resolution including sign.
Verified SIMATIC S7-200 SMART analog-input and temperature-measurement options.
Verified analog, signal-board and compact I/O choices for S7-200 SMART systems.
Published communication and digital signal-board options with verified contact details.
Expandable S7-200 SMART CPU hosts and compatible compact control choices.
Verified Siemens analog-input, analog-output and temperature-measurement modules.
Verified S7-200 SMART CPUs, communication boards and compact digital I/O.
Published 8 mm and NSv proximity probe configurations.
Verified 5 mm, 11 mm, 25 mm, 50 mm and ceramic-capped probe options.
Verified probe housings, mounting studs and system cable accessories.
Published velocity, thrust, speed and vibration-sensing products.
Verified protection relays, controllers and machinery-monitoring products.
Additional verified automation, monitoring and I/O products published on Nordwel.
Use the exact manufacturer order number and verify the system constraints before procurement.
Match the order number to 6ES7288-5AE01-0AA0.
Select one official voltage range or 0–20 mA current.
Do not connect thermocouple, RTD or resistance sensors to this board.
Check that the target CPU provides the required signal-board slot.
Use 11 bits plus sign for voltage or 11 bits for current in scaling calculations.
Use the exact Siemens data sheet and China RoHS record for the delivered article.
Selected specialist-brand products requested for regional projects and available on Nordwel.
Auxiliary relay option for protection and control applications.
Recent Middle East inquirySIMATIC S7-200 SMART RS485 communication board.
Recent Middle East inquiryRemote I/O gateway for demanding process-system environments.
Specialist brandReplacement inverter driver board for installed industrial systems.
Specialist brandAmplifier transducer for load-cell signal conditioning.
Specialist brandIndustrial power-supply model for legacy equipment support.
Specialist brandAnswers below use Siemens official product documentation for this exact order number.
It is the SIMATIC S7-200 SMART SB AI01 signal board with one analog input.
The supported ranges are ±10 V, ±5 V and ±2.5 V.
Yes. It supports a 0 to 20 mA current input range.
Voltage is 11 bits plus sign, current is 11 bits, and the maximum including sign is 12 bits.
No. Thermocouple input is not supported.
No. RTD and resistance measurement are not supported.
The exact data sheet lists 0.4 W.
SB AI01 measures 35 × 52.2 × 16 mm and weighs about 20 g.
