A multifunction X20 module combining digital I/O, a universal counter pair, linear movement generation, SSI encoder support and timestamped operation.
Brand:
OthersItem NO.:
X20DS1319Goods Stock:
1Part Number:
X20DS1319Description:
A multifunction X20 module combining digital I/O, a universal counter pair, linear movement generation, SSI encoder support and timestamped operation.A multifunction X20 module combining digital I/O, a universal counter pair, linear movement generation, SSI encoder support and timestamped operation.
| Digital inputs | 4 |
|---|---|
| Configurable digital I/O | 4 |
| Universal counters | 1 pair |
| Encoder support | SSI |
| Movement function | Linear movement generator |
| Timing functions | Timestamps and time-triggered I/O |
| Module pitch | 12.5 mm |
| Required terminal | X20TB12, separate |
| Required bus module | X20BM11, separate |
Source: B&R X20DS1319 official product record.
